KUSP 2.0: KIM Utility for Serving Potentials

Documentation Status

_images/kusp.png

KUSP was developed to provide an easy and quick way to deploy any potential, ML or otherwise to the KIM API. It ensured that any valid ML model was on equal footing with OpenKIM supported interatomic potentials, and could directly guide uses in improving their models or datasets etc.

With the latest 2.0 release kusp has become even easier to use, with more powerful features to run your models with almost any simulator. With new capabilities, like hot-reloading of models at runtime, kusp is also a powerful prototyping system which is truly independent of any simulator.

Another added benefit of KUSP 2.0 is the included KUSP KIM-API model driver. Using it you can port any python callable object as a full KIM-API model. It achieves this by using the Python C++ API and Pybind11, faithfully recreating the exact python env at runtime, from with in the KIM-API ecosystem.

Please note that KUSP is primarily designed for model validation and development, and for high performance production runs, you are advised to use the KIM model drivers.

Difference between KUSP and TorchML model driver

KUSP uses the Python interpreter to run any model in its native environment. KIM API communicates with the model using the sockets interface in serve mode, and direct foreign function interface (via Pybind11) in the export mode.

_images/KUSP_mech.png

While this is easy and quick, it is not the most efficient way to run ML models. Besides the overhead of Python interpreter, you also have the communication overhead between Python and C++ code, and overhead of the data transfer process, which is usually 100-400ms per call in the sockets interface. This is not a problem for very large models, but for small models, this overhead can be significant. This is on top of inherent Python performance limitations.

_images/transport.png

Addressing the previous limitation, KUSP is now designed to be completely portable. With KIM-API and all the dependencies installed, you can install any KUSP exported model as simply as kim-api-collections-management install user <model>.

Key capabilities

  • Turnkey CLI: kusp install, kusp serve, and kusp export cover the full lifecycle from registering the bundled portable model and driver artifacts to packaging a new model.

  • Hot reload server: kusp serve model.py hosts a TCP endpoint with Ctrl+C-based hot reload, so editing the Python source immediately affects subsequent simulator calls.

  • Rapid export: kusp export snapshots your Python model along with resources, environment metadata, creating a portable KIM model.

See :doc:example for a walk-through that exercises every piece.

KUSP Protocol

KUSP uses a simple protocol to communicate with the KIM API. The protocol expects the configuration information in following order,

    [Necessary] First 4 bytes: size of integer on the system (int_width), 32 bit integer
    [Necessary] Next int_width bytes: number of atoms (n_atoms), default int_width integer
    [Necessary] Next int_width x n_atoms bytes: atomic numbers
    [Necessary] Next 8 x 3 x n_atoms bytes: positions of atoms (x, y, z), double precision
    [Optional] Next int_width x n_atoms bytes: Which atoms to compute energy for (contributing atoms)

Callable Signature

Dependencies

KUSP is a minimal dependency package, but it requires KIM API to serve potentials in simulator agnostic framework. Without KIM API user would need to implement own simulator interface.

Environment Variables

Env. variable

Use

KUSP_CONFIG

Runtime variable for interactive TCP run (kusp serve mode). It tells the client about the loaction of the config file containing basic information like influence distance of the model, and server host/port. Config file can be automatically generated by KUSP (name formatted as kusp_config_{pid}_{timestamp}.yaml) or can be provided by user as --kusp-config flag.

KUSP_PYTHON_EXEC

Install time variable to help locate python installation. CMake sometimes struggles to find correct python installation, especially conflating the default system python on Linux installations. You can set the correct python executable to help CMake find it. Please set if env variable becore kusp install command if required. See troubleshooting section for details on possible issues.

Citation

If you use KUSP in your research, or find it useful, please cite the following paper, accessible here.

@inproceedings{gupta2024kusp,
  title={KUSP: Python server for deploying ML interatomic potentials},
  author={Gupta, Amit and Tadmor, Ellad B and Martiniani, Stefano},
  booktitle={AI for Accelerated Materials Design-Vienna 2024}
}
